T1

T1
FRAME
proimages/icon/Model.png Model T-1
proimages/icon/SP.png SP 10SPD
proimages/icon/Size.png Size 10.5''
proimages/icon/Color.png Color Titanium
SHIFTER SYSTEM
proimages/icon/Frame.png Frame Titanium 3AL-2.5V
proimages/icon/Fork.png Fork SAGA T-150 1-1/8" Titanium 3AL-2.5V
proimages/icon/HP.png Head Parts Inetegrated 1-1/8"
proimages/icon/BBP.png B.B Parts SHIMANO BSA
proimages/icon/S-Pin.png S./Pin SAGA Alloy/Carbon
proimages/icon/Shifter-R.png Shifter SHIMANO SL-R780 10SPD
proimages/icon/FDerailleur.png F/Derailleur NIL
proimages/icon/RDerailleur.png R/Derailleur SHIMANO ULTEGRA RD-6700-SS
proimages/icon/CWheel.png C/Wheel SHIMANO ULTEGRA FC-6700 53T
proimages/icon/Freewheel.png Freewheel SHIMANO ULTEGRA CS-6700 11-25T
proimages/icon/Chain.png Chain SHIMANO ULTEGRA CN-HG6701-10
proimages/icon/Rim.png Rim 20" ALEXRIMS Double wall 20H, W/CSW
proimages/icon/Hub.png Hub NOVATEC Sealed Bearing hub 20H
proimages/icon/Spokes.png Spokes Stainless steel ED Black
proimages/icon/Tire.png Tire MAXXIS Overdrive Elite 20''*1.35
proimages/icon/Saddle.png Saddle SAN MARCO
proimages/icon/Stem.png Stem Titanium 3AL-2.5V
proimages/icon/Hbar.png H/BAR SAGA T-130 Titanium 3AL-2.5V
proimages/icon/seatpost.png Seatpost SAGA T-350 Titanium 3AL-2.5V
proimages/icon/Brake.png Brake AVID
proimages/icon/Shifter-R.png B/Lever SHIMANO BL-R550
proimages/icon/Weight.png Weight 8.4kg
Frame size Top tube(A) Head tube length(B) Fork length(C) Head tube angle(D) Bottom bracket drop(E) Chain stays(F) Seat tube angle(G) Seat tube(H)
10.5" 540.1mm 84.9mm 284.9mm 71° 30mm 400mm 78.3° 254mm
