GALLANT3.0

GALLANT3.0
GALLANT3.0
FRAME
proimages/icon/Model.png Model GALLANT 3.0
proimages/icon/SP.png SP 27SPD
proimages/icon/Size.png Size 16'',18'',20",22''
proimages/icon/Color.png Color Matte Black&Gray&Blue, Matte Black&Gray&Yellow
SHIFTER SYSTEM
proimages/icon/Frame.png Frame Aluminum 6061
proimages/icon/Fork.png Fork SAGA 360(650B), Travel:100mm W/Lock out
proimages/icon/HP.png Head Parts SAGA Inetegrated 1-1/8"
proimages/icon/BBP.png B.B Parts NECO 910P Cartridge Type
proimages/icon/S-Pin.png S./Pin Alloy Sand Black
proimages/icon/Shifter-R.png Shifter SHIMANO ALTUS 27SPD
proimages/icon/FDerailleur.png F/Derailleur SHIMANO ALTUS
proimages/icon/RDerailleur.png R/Derailleur SHIMANO ALTUS
proimages/icon/CWheel.png C/Wheel PROWHEEL FLINT 44-32-22T
proimages/icon/Freewheel.png Freewheel SHIMANO ACERA CS-HG200 11-32T
proimages/icon/Chain.png Chain KMC Z99
proimages/icon/Rim.png Rim 650B Alloy Double wall 32H
proimages/icon/Hub.png Hub JOYTECH Alloy Black 32H
proimages/icon/Spokes.png Spokes Steel ED Black
proimages/icon/Tire.png Tire CST 27.5''*1.95
proimages/icon/Saddle.png Saddle SAGA
proimages/icon/Stem.png Stem SAGA Alloy Sand Black
proimages/icon/Hbar.png H/BAR SAGA Alloy Sand Black
proimages/icon/seatpost.png Seatpost SAGA Alloy Sand Black
proimages/icon/Brake.png Brake SHIMANO BR-M315 W/180mm Rotor
proimages/icon/Shifter-R.png B/Lever SHIMANO BL-M315
proimages/icon/Weight.png Weight 13.5kg
proimages/Mountain_Bike/GALLANT-SIZE.jpg
Frame size Top tube(A) Head tube length(B) Fork length(C) Head tube angle(D) Bottom bracket drop(E) Chain stays(F) Seat tube angle(G) Seat tube(H)
16" 555.6mm 130mm 460mm 71° 45mm 435mm 66.9° 406mm
18" 580.7mm 130mm 460mm 71° 45mm 435mm 66.9° 457mm
20" 598.3mm 140mm 460mm 71° 45mm 435mm 66.9° 508mm
22" 608mm 150mm 460mm 71° 45mm 435mm 66.9° 558mm
