F-1
.jpg "F-1")
| FRAME | ||
 |
Model | F-1 |
 |
SP | 18SPD |
 |
Size | 14" |
 |
Color | Matte Black / Lake Green / Matte Gray |
| SHIFTER SYSTEM | ||
|---|---|---|
 |
Frame | Aluminum |
 |
Fork | Aluminum |
 |
Head Parts | Inetegrated 1-1/8" - 1-1/2'' |
 |
B.B Parts | Cartridge Type |
 |
S./Pin | Alloy Sand Black |
 |
Shifter | SHIMANO SORA 2*9SPD |
 |
F/Derailleur | SHIMANO SORA |
 |
R/Derailleur | SHIMANO SORA |
 |
C/Wheel | PROWHEEL ATIA 52-42T |
 |
Freewheel | SHIMANO CS-HG200 11-32T |
 |
Chain | KMC Z99 |
 |
Rim | 20" Alloy Black |
 |
Hub | Alloy Black F-24H/R-28H |
 |
Spokes | Steel ED Black |
 |
Tire | Kenda 20''*1.5'' |
 |
Saddle | SAGA |
 |
Stem | SAGA Alloy Sand Black |
 |
H/BAR | SAGA Alloy Sand Black |
 |
Seatpost | SAGA Alloy Sand Black |
 |
Brake | SHIMANO BR-M375 DISC BRAKE |
|
B/Lever | JAK L-11SB ALLOY |
 |
Weight | 11.6kg |
| Frame size | Top tube(A) | Head tube length(B) | Fork length(C) | Head tube angle(D) | Bottom bracket drop(E) | Chain stays(F) | Seat tube angle(G) | Seat tube(H) |
| 14" | 590mm | 105mm | 300mm | 73° | 40mm | 406mm | 82° | 356mm |
